4K SDI / IP ST 2110 Conveter
VICO-4L-2110 is our latest addition to the VICO series, enabling up to 4K video uncompressed transport over IP. The video interface can be configured as 12G-SDI, 4x3G-SDI or 4xHD-SDI. The IP interface is supporting up to 25G. The 1RU chassis can enable two channels for encapsulation or decapsulation, independently configured through the front panel, or through software interface. Video, Audio and Ancillary transport is according to ST2110, ST2059 and supporting NMOS IS-04/IS-05, with optional ST2022-7 support for stream redundancy.
| ・Video Input Interface | 1x 4K(12G-SDI/4x 3G-SDI) or 4x HD (HD/3G-SDI) |
| ・Transport Protocol | SMPTE ST2110 -10, -20, -30, -40 |
| ・Audio | Up to 16 channels per input |
| ・Decapsulate Sync | PTP (ST2059-1/-2), External Sync |
| ・Low Latency | User-configurable from several lines to 1 frame (16.6/33.33ms) |
| ・Control | AMWA NMOS IS-04/05, SNMP, WebGUI |
| ・Size | 1RU Rack Mount |
| ・Number of Channels | 1x 4K(12G-SDI/4x 3G-SDI) or 4x HD (HD/3G-SDI) per board *Up to 2 boards can fit in 1RU |
| Resolution/Frame Rate | 4K 3840x2160 59.94p/50p HD 1920x1080 59.94i/50i/59.94p/50p |
Control | Front Panel, WebGUI, SNMP, NMOS |
| Chroma/Bit Depth | 4:2:2 / 10bit | Power Supply | Hot Swap, Redundant Power Supply (Optional) |
| Video & Audio I/F | 4K: 12G-SDI x1 or 3G-SDI x4 4x HD (HD-SDI or 3G-SDI) |
Power | AC100-240V, 30W |
| Transport I/F | SMPTE ST2110 SFP28(#1) 25GbE | Size (W x D x H) | 435 x 260 x 44.5 mm |
| Decap Sync | PTP (ST 2059-1/-2), External Sync | Weight | Approx. 5Kg |
| Alarm Output | OLED Display, SNMP Trap, Web GUI Log | Operating Temperature/Humidity | 0℃~35℃ / 20% ~ 80% RH |
