HD/3G-SDI ⇔ JPEG-XS IP ST2110 Converter
The VICO-2L-XS is empowered with a visually lossless JPEG-XS codec, enabling ultra-low latency transmission of HD video signals over IP ST2110-22. It includes ST2022-7 redundancy for data loss protection. The 1RU chassis can host up to two HD channels and is equipped with hot-swappable redundant power supplies. Users can freely switch between encoder and decoder modes on a per-channel basis.
| ・Low Latency | User-configurable from 1 ms to 1 frame (16.66/33.33 ms) |
| ・Compression Ratio | 6:1 ~ 80:1 (selectable from 14 levels) |
| ・Video Quality | Visually Lossless |
| ・Supported Standards | SMPTE ST2110/ST2022-7/ST2059/NMOS IS-04/05 |
| ・Codec | JPEG-XS (ISO/IEC 21122-1:2019) |
| ・Size | 1RU Rack Mount |
| ・Channels | Up to 2 channels (with expansion option) |
| ・Audio | Up to 16 channels per video channel |
| Resolution/Frame Rate | HD 1920x1080 59.94i/50i/59.94p/50p | Control | Front Panel, WebGUI, SNMP, NMOS |
| Chroma/Bit Depth | 4:2:2 / 10bit | Power Supply | Hot Swap, Redundant Power Supply (Optional) |
| Video & Audio I/F | HD (HD-SDI or 3G-SDI) | Power | AC100-240V, 30W |
| JPEG XS IP I/F | 10GbE SFP+ (Port #1 and #2) | Size (W x D x H) | 435 x 260 x 44.5 mm |
| Decoder Sync | PTP (ST 2059-1/-2), External Sync | Weight | Approx. 5Kg |
| Alarm Output | OLED Display, SNMP Trap, Web GUI Log | Operating Temperature/Humidity | 0℃~35℃ / 20% ~ 80% RH |
