aura UHD studio Gen2 24/27/32

12G-SDI Professional Film and Television Production Monitor

The RGBlink aura UHD studio is a next-generation broadcast-grade 4K HDR monitor.

It features groundbreaking functionality that allows it to work directly with professional applications like Adobe Premiere Pro and DaVinci Resolve via its Thunderbolt™ port. With a UHD (3840×2160) screen, it supports up to 8K input via quad-link 12G SDI signals (with backward compatibility for 4K@60Hz).

The monitor supports 3D LUTs with high-precision tetrahedral interpolation algorithms and includes professional features such as HDR formats like SMPTE ST2084(PQ) and HLG, various gamma curves, and camera Log. It contributes to precise video representation and workflow efficiency in all fields where high image quality is required, including the film, television, and advertising industries.

Catalogues
Contact us

Key Features

*27を除く

Order Codes

Main Unit and Redundant Power Supply
Product Code Description
410-2380-01-1 aura UHD studio 24 (Gen 2)

  • 23.8-inch UHD monitor (3840x2160 resolution, 1000nit brightness)
    •
  • Equipped with 4x 12G SDI inputs and 2x 4K60 HDMI inputs
    •
  • 1x Thunderbolt input (for preview signals from video editing apps like DaVinci Resolve)
    •
  • 1x optical fiber input (requires 12G-SFP module)
    •
  • Supports quad-link 8K input (2SI)
    •
  • Supports HDR
    •
  • Simultaneous monitoring of 4x 12G SDI signals in quad-view mode
410-2700-01-1 aura UHD studio 27 (Gen 2)

  • 27-inch UHD monitor (3840x2160 resolution, 800nit brightness)
    •
  • 4x 12G SDI inputs and 2x 4K60 HDMI inputs
    •
  • 1x Thunderbolt input (for preview signals from video editing apps like DaVinci Resolve)
    •
  • 1x optical fiber input (requires 12G-SFP module)
    •
  • Supports quad-link 8K input (2SI)
    •
  • Supports HDR
    •
  • Simultaneous monitoring of 4x 12G SDI signals in quad-view mode
410-3200-01-1 aura UHD studio 32 (Gen 2)

  • 32-inch UHD monitor (3840x2160 resolution, 1000nit brightness)
    •
  • 4x 12G SDI inputs and 2x 4K60 HDMI inputs
    •
  • 1x Thunderbolt input (for preview signals from video editing apps like DaVinci Resolve)
    •
  • 1x optical fiber input (requires 12G-SFP module)
    •
  • Supports quad-link 8K input (2SI)
    •
  • Supports HDR
    •
  • Simultaneous monitoring of 4x 12G SDI signals in quad-view mode
490-2000-01-0 V-mount battery plate kit for aura UHD Gen 2 23.8-inch monitor

  • Kit includes one V-mount battery plate (cannot be ordered individually).
490-2000-02-0 V-mount battery plate kit for aura UHD Gen 2 27/32-inch monitors

  • Kit includes two V-mount battery plates (cannot be ordered individually).

Common


Item Details
I/O

  • Inputs

    • 12G-SDI: 4x BNC
      •
    • HDMI: 2x HDMI-A (※In1 is not HDCP compliant)
      •
    • SFP: 12G Optical Fiber (SM)
      •
    • USB-C/Thunderbolt3: 1x USB-C (※Supports preview of DaVinci app output only, does not support desktop duplication or extension)
      •

    •
  • Outputs

    • 12G-SDI: 4x BNC
      •

SDI Signal Formats
  • 720p@50/59.94/60;
  • 1080p@23.98/24/25/29.97/30;
  • 1080p@50/59.94/60;
  • 2048×1080@23.98/24/25/29.97/30p/psf,47.95/48/50/59.94/60p;
  • 3840×2160p@23.98/24/25/29.97/30/50/59.94/60;
HDMI Signal Formats
  • 720p@50/59.94/60
  • 1080i@50/59.94/60
  • 1080p@23.98/24/25/29.97/30/50/59.94/60
  • 3840×2160p@23.98/24/25/29.97/30/50/59.94/60
  • 4096×2160p@23.98/24/25/29.97/30/50/59.94/60
Audio
  • Audio De-embedding: Supported
  • Audio Meter: 16 channels (max 8 channels can be displayed simultaneously)
  • Built-in Speaker: 1×8Ω/0.5W
  • Headphones: 1x Stereo Mini Jack
General
  • Control/Update: 1×RJ45
  • GPI: GPI1-5, 1×RJ-45
  • Serial Port: RS-422, 2×RJ-45 (1 input, 1 output)
Supported Standards
  • HDMI IN1:
    • HDCP 1.X
    • HDCP 2.2
  • SDI:
    • SMPTE-425M-A/B
    • SMPTE-274M
    • SMPTE-296M
    • SMPTE ST 2036-1:2009
    • SMPTE ST 2048-2:2011
    • SMPTE ST 2081
    • SMPTE ST 2082
